HOSE ASSEMBLY TEST RIG / HOSE FLUSHING MACHINES – UNIFLEX TEST RIGS, THE MOST TRUSTED HOSE TEST RIG SUPPLIER

Uniflex test rigs enable hose manufactures to carry out a visible hose assembly test , which can then be fully certified to give full traceability. Manufactured to the highest standards the easy to operate Uniflex test rigs allow fast and comprehensive testing of single or multiple hose assemblies to the latest industry standards.

Uniflex hose flushing machines quickly removes hose contamination to ensure stringent industry hose cleanliness standards can be achieved.

Uniflex are the leading supplier of Uniflex Test Rigs, Hose Test Rig, Hose Test Rig Supplier, Hose Assembly Test Rig and Hose Flushing Machines.

    • Uniflex Test Rigs

      INTERGRATED TANK WITH FILTER – UNIFLEX TEST RIGS

      In case of leakage the testing fluid will flow back into the tank without any loss.

    • Hose Test Rig

      ECOLINE

      Work space optimized: between front plate and dies around machine heads.

    • Hose Test Rig

      UNIVERSAL HOSE TEST RIG/ HOSE ASSEMBLY TEST RIG

      Hose Assembly Test Rig and Hose Flushing Machines for all types of hoses and fittings.

NEW
CATALOGUE AVAILABLE

DOWNLOAD OUR FULL BROCHURE

  • captcha

HOSE TEST RIGS

PRODUCT CODE PRODUCT PICTURE (Click to enlarge) PRODUCT VIDEOS TEST PRESSURE DRIVE TANK
DIMENSIONS
CAPACITY 1ST CLASS ADVANTAGES
PRODUCT CODEP160 PRODUCT PICTURE (Click to enlarge)P160_1 Hose Test Rig Supplier PRODUCT VIDEOS TEST PRESSURE150/1300 bar DRIVEIntensifier TANK1590×795
x370mm
CAPACITY7 bar,
20 NI/min
1ST CLASS ADVANTAGES2-icon-test
PRODUCT CODEP160 ECOLINE PRODUCT PICTURE (Click to enlarge)P160 Ecoline Hose Assembly Test Rig PRODUCT VIDEOSS1M TEST PRESSURE150/1300 bar DRIVEIntensifier TANK1200×600
x250mm
CAPACITY7 bar,
20 NI/min
1ST CLASS ADVANTAGES3icon
PRODUCT CODEP200 PRODUCT PICTURE (Click to enlarge)P200 Hose Flushing Machines PRODUCT VIDEOS TEST PRESSURE150/1300 bar DRIVEIntensifier TANK1590×795
x370mm
CAPACITY7 bar,
20 NI/min
(400v/50 hz
/3Ph)
1ST CLASS ADVANTAGES2-icon-test
PRODUCT CODEP300 PRODUCT PICTURE (Click to enlarge)P300_a_frei Hose Flushing Machines PRODUCT VIDEOSS1M TEST PRESSURE100/1000 bar DRIVEHydraulic
aggregate 3Kw
with pressure
intensifer
TANK3750×1450
x870mm
CAPACITY13 l/min
(400v – 50 hz
– 3 Ph)
1ST CLASS ADVANTAGES4icon-1

HOSE FLUSHING MACHINES

PRODUCT CODE PRODUCT PICTURE (Click to enlarge) PRODUCT VIDEOS DRIVE FLOW MAX AIR
CONSUMPTION
WORKING
RANGE
MAX
LENGTH
CAPACITY WORKING
AREA
PRODUCT CODERG10 PRODUCT PICTURE (Click to enlarge)RG10_frei Hose Flushing Machines PRODUCT VIDEOS DRIVEDiaphram
pump
7 Bar Air
FLOW180I/min MAX AIR250 NI/min WORKINGBIS / up to 2”ID MAX20m/65 feet CAPACITY215 I WORKING800×1600
PRODUCT CODERG2 PRODUCT PICTURE (Click to enlarge)RG2  Hose Flushing Machines PRODUCT VIDEOS DRIVEDiaphram
pump
7 Bar Air
FLOW25 I/min MAX AIR100 NI/min WORKINGBIS /
up to 1 1/4”ID
MAX2,5m/8 feet CAPACITY38 I WORKING350×750
